RS-VGT52A Vertical Flow Packaging Machine
Specially designed for QUADRO packing, equipped with high-precision multi-head weighers for accurate measurement. It delivers excellent packaging results and can be seamlessly integrated into automated production lines.
Packaging Effect
RS-VGT52A Data Sheet
| Model | RS-VGT52A |
| Film Width(mm) | 220~520 |
| Pouch Width (mm) | Front width:70~200 |
| Edgesealing width:5~7 | |
| Side width:30~100 | |
| PouchLength(mm) | 100~350 |
| Film Thickness(mm) | 0.04~0.09 |
| Pouch Type | Pillow bag,gusseted bag,block bottom(corner seal) |
| Packing Speed (bpm) | 10~35 |
| Total Power (kW) | 4.3 |
| Air Pressure (MPa) | 0.8 |
| Air Consumption(m³/min) | 0.35 |
| Weight(KG) | 800 |
| Dimensions (mm) | 2100×1400×2100 |
Technology
● Continuous Film Pulling Technology:
It is designed with a continuous film-pulling mechanism, featuring a simple structure, high efficiency, and durability, ensuring stable operation during long-term production.
● Servo Technology:
Maintenance-free servo technology reduces maintenance costs and time.
● PLC Control System:
The PLC control system ensures precise machine operation, enabling smooth production and excellent output quality, thereby enhancing production efficiency and product quality.
● Remote Access and Maintenance:
The open machine concept supports remote access and maintenance, allowing technicians to perform remote diagnostics and troubleshooting, improving maintenance efficiency and response time.
